Victron Battery Monitor BMV-712 SMART Bluetooth BMV 712 BAM03071200R

Description

Battery Monitor BMV-712 Smart

• Supply voltage range 6.5 – 70 VDC
• Current draw, back light off < 1mA
• Input voltage range, auxiliary battery 6.5 – 70 VDC
• Battery capacity (Ah) 1 – 9999 Ah
• Operating temperature range -40 +50°C (-40 – 120°F)
• Measures voltage of second battery, or
• temperature, or midpoint Yes
• Temperature measurement range -20 +50°C
• VE.Direct communication port Yes
• Bistable relay 60V / 1A normally open (function can be inverted)

RESOLUTION & ACCURACY (with a 500 A shunt)

• Current ± 0.01A
• Voltage ± 0.01V
• Amp hours ± 0.1 Ah
• State of charge (0 – 100%) ± 0.1%
• Time to go ± 1 min
• Temperature (0 – 50°C or 30 – 120°F) ± 1°C/°F
• Accuracy of current measurement ± 0.4%
• Accuracy of voltage measurement ± 0.3%

INSTALLATION & DIMENSIONS

• Installation Flush mount
• Front 63mm diameter
• Front bezel 69 x 69mm (2.7 x 2.7 inch)
• Shunt connections bolts M10 (0.3937 inch)
• Body diameter and depth 52mm (2.0 inch) and 31mm (1.2 inch)
• Protection category IP55 (not intended for outdoor use)

STANDARDS

• Safety EN 60335-1
• Emission / Immunity EN 55014-1 / EN 55014-2
• Automotive ECE R10-4 / EN 50498

ACCESSORIES

• Shunt (included) 500A / 50mV
• Cables (included)
• 10 meter 6 core UTP with RJ12 connectors, and cable with 1Amp slow blow fuse for ‘+’ connection
• Temperature sensor Optional (ASS000100000)
